適用材料Applicable material
樹脂顆粒、樹脂粉末、碳酸鈣、滑石粉、樹脂膜粉粒品、玻璃纖維、碳纖維
Resin particles, resin powder, calcium carbonate, talc, resin film powder, glass fiber, carbon fiber
特點Characteristics
1、無需工具即可分解主要部件（1分鐘內）
2、全量排出時的殘留量很少，清掃簡單。
3、占用面積小。設置容易。
4、集約化產品、重量輕。
5、螺桿與攪拌器各自單獨驅動。
1. Decompose the main parts without tools (within 1 minute)
2. The residual amount is small when the whole amount is discharged, and the cleaning is simple.
3. The occupied area is small. Easy to set up.
4. Intensive products and light weight.
5. The screw and the agitator are each driven separately.
規格Specification
|
型號 Model |
流量范圍 Flow rate range |
料斗容量 Hopper capacity |
稱量 Weigh capacity |
產品重量 Feeder weight |
電源 Power supply |
|
HF-W-1 |
10-100kg/h |
50L |
30kg |
約65kg Approx65kg |
380VAC,3phase,0.55kVA |
|
HF-W-2 |
50-300kg/h |
80L |
50kg |
約85kg Approx85kg |
380VAC,3phase,0.75kVA |
|
HF-W-3 |
200-1000kg/h |
120L |
100kg |
約180kg Approx180kg |
380VAC,3phase,1.5kVA |
|
HF-W-4 |
500-3000kg/h |
200L |
200kg |
約250kg Approx250kg |
380VAC,3phase,2.2kVA |
（ ）內為控制模塊KB-2500G一體式的數據。 Specifications in parenthesis( )are for modeis unitized with control module KB-25000G
